Aitech’s C695 is a high-performance 3U VPX PCI Express Switch for embedded and harsh environment applications.
PCIe switching is performed by the IDT 89H32NT24AG2 32-lane/24-port Gen2 PCIe switch, which provides powerful
switching capabilities and integrated DMA engines for fast data transfers.
Up to eight PCIe x4 ports are routed from the IDT switch to the C695 VPX backplane connectors. When the C695 is
equipped with the optional XMC site, eight of the IDT switch PCIe lanes are routed to the XMC and XMC I/O is routed to the
VPX backplane connectors.
Additional backplane PCIe port/lane grouping options are user configurable via the on-board EEPROM. User configuration
options also include Transparent and Non-Transparent (NT) ports and upstream/downstream port configuration.
| IP Classification | None |
|---|---|
| Number of ports | 8 |
| Mounting | 3U |
| Sector | Defence |
